Functional Specifications
Temperature Range: -20 to 500°C (-4 to 932°F)
Resolution: 0.1°C
Optical Resolution: 13: 1 @ 90% energy
Accuracy: mV: ±1.5% of reading or ±2°C; t/c: ±1.5% of reading or ±4°C
Repeatbility: ±0.5% of reading or ±2°C
Spectral Response: 8 to 14 microns
Response Time: 150mSec
Emissivity: 0.10 to 1.10 (adjustable)
Transmissivity: 0.10 to 1.00 (adjustable)
Outputs: Voltage
General Specifications
Power: 12 - 24 VDC @ 20 mA
Output Impedance: 100 Ω
Min. Load impedance: 50 kΩ
Power Supply: 12-24 VDC ±20% @ 10mA
Digital output: Two-way RS-232
Alarm output: Transistor, 24VDC ±20% <20mA
